Super Enamelled Copper Wires

Stockist of "ESS ELL" Brand supper enamelled copper wire & submersible winding wire of copper, Pvc insulated & Poly wrapped.

TECHNICAL DETAILS - TESTING & APPEARANCE
Enamel Base	Modified - Polyester	Modified - Polyester	Polyester Limide	Dual Coat (Lmide - Amide)
Thermal Rating	130^o	155^o	180^o	200^o
Thermal Class	B	F	H	H+
Colour	Light Brown To Brown	Dark Brown	Brown	Light Brown
Range	0.122mm. To 4.0 mm	0.122mm. To 4.0 mm	0.122mm. To 4.0 mm	0.5 mm To 2.0 mm
Old Specification	I .S - 48000 PT -V	I .S - 48000 PT -V (Type II)	I .S - 48000 PT - IX/VIII B	I .S - 48000 PT -XIII
New Specification	I. S. - 13730 PT - 34	I. S. - 13730 PT - 3	I. S. - 13730 PT - 8	I. S. - 13730 PT - 13
Cut Through	240^o C	240^o C	300^o C	320 C
Heat - Stock	155^oC	175^oC	200^oC	220C
Abrasion Resistance Flexibility Solvent Resistance	GOOD	GOOD	VERY GOOD	EXCELLENT
Application	All General Electric Equipment	General Purpose Rotating and Static Electrical Equipment	For F H P Motors, Hand Tools, Electromagnetic Coils	Special Motor including Hermetic Motors
Special Characteristics	Ideal For Rewinders	Balanced Electrical & Mechanical Properties Good For O.E.Ms.	Higher Thermal Endurance Excels Modified Polyester In Thermoplastic Flow, Aveasion And Heat Shock	Very High Thermal Property, Excellent for Hermetic Use.
